KEB COMBIVERT G6 Programming Manual

42
Fieldbus Parameters
Parameter Id-Text Name CANSDOIndex
fb17 PD1 in offset 0x2191
fb27 PD2 in offset 0x219B
fb37 PD3 in offset 0x21A5
Subindex 0
Number of subindi-
zies
8
Object type ARRAY
Data length unsigned Byte
Access Read write
Meaning Speciesthenumberofsub-indicesinthisobject.
Subindex 1...8
Data length unsigned Byte
Access Read write
Meaning Indicatestheoffsetoftheassignmentinthe8byteprocessdataeld.
Position of the value of the mapped parameter.
Coding 0...7 for byte 0...7
Parameter Id-Text Name CANSDOIndex
fb18 PD1 in type 0x2192
fb28 PD2 in type 0x219C
fb38 PD3 in type 0x21A6
Subindex 0
Number of subindi-
zies
8
Object type ARRAY
Data length unsigned Byte
Access Read write
Meaning Speciesthenumberofsub-indicesinthisobject.
Subindex 1...8
Data length unsigned Byte
Access Read write
Meaning ThevaluedenestheparametertypeoftheselectedPDparameter.
Coding
0 off;noparametertypedened
1 Long
2 Word
3 Byte
