PRODUCT DESCRIPTION
2.4 Part code
x x G 6 x x x - x x x x
Heatsink version
1
0: Air-cooling
1: Flat rear
Control,
keyboard,
display
1
A: G6K-G Open-loop without keyboard/display
B: G6K-G Open-loop with keyboard/display
0: G6-G Open-loop without keyboard/display
1: G6-G Open-loop with keyboard/display
2: G6P-S SCL
2
closed-loop without keyboard/display
3: G6P-S SCL
2
closed-loop with keyboard/display
4: G6L-M
ASCL
3
closed-loop without keyboard/display
5: G6L-M ASCL
3
closed-loop with keyboard/display
Switching frequency;
Short time current limit;
Overcurrent cut-off
1
5: 4 kHz / 150% / 180%
9: 4 kHz / 180% / 216%
A: 8 kHz / 180% / 216%
Voltage /
Connection
1
0: 1ph 230 V AC/DC
1: 3ph 230 V AC/DC
3: 3ph 400 V AC/DC
5: 3ph 400 V DC
A-Z:
Customer/specialversions(rmware,hardware,
download)
Housing A, B, C, E
Variants
0:
Withoutlter,withoutbraking transistor,
without safety function STO
1:
Withoutlter,withbrakingtransistor,
without safety function STO
3:
Internallter,withbraking transistor,
without safety function STO
A: like 0 with STO H: lika A with f=0 Hz
B: like 1 with STO I: like B with f=0 Hz
D: like 3 with STO L: like D with f=0 Hz
Control type
C: Analog/digital (standard)
D: CAN®
4
E: IO-Link®
5
F: EtherCAT®
6
I: VARAN
Series COMBIVERT G6
Unit size 07…19
Table 1: Part code
1
Not valid at customer/special versions
2
SCL = Sensorless Closed Loop
3
ASCL = Asynchronous Sensorless Closed Loop
4
CANopen® is registered trademark of CAN in AUTOMATION - International Users and Manufactur-
ers Group e.V.
5
IO-LINK® is registered trademark of PROFIBUS user organisation e.V.
6
EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation
GmbH, Germany
