• ”Integral solid state short circuit protection does not provide branch circuit protec-
tion. Branch circuit protection must be provided in accordance with the Manufacturer
Instructions, National Electrical Code and any additional local codes”.
• Wiring terminals are marked to show a range of values or a nominal value of tighten-
ing torque in pound-inches to be applied to the clamping screws as shown below:
Input/Output terminals: 5…7 lb-in (0.56…0.79 Nm)
• Use in a Pollution Degree 2 environment.
• "Use 60/75°C Copper Conductors Only"
• “During the UL evaluation, only Risk of Electrical Shock and Risk of Fire aspects
were investigated. Functional Safety aspects were not evaluated”
• In order to comply with CSA C22.2 No. 14-2010 (cUL) following external Input
Chokes need to be installed: See table 1 below!
Table 1: Mains input chokes for CSA applications:
Cat. No. Housing Input Voltage [Vac] Reactor Cat. No. FLA Inductance [mH]
07G6 A 240 / 1ph in preparation
09G6 A 240 / 1ph in preparation
07G6 A 480 / 3ph 07DRB08-4951 3 x 6A 4.88
09G6 A 480 / 3ph 10DRB08-3751 3 x 8A 3.66
10G6 A 480 / 3ph 10DRB08-3751 3 x 8A 3.66
Branch Circuit Protection for G6 - A Drive series
I) Fuses:
Cat. No. Housing Input Voltage
[Vac]
Class CC, J or RK5
UL248 Fuse rating 600V [A]
07G6 A 240 / 1ph 15
09G6 A 240 / 1ph 20
07G6 A 480 / 3ph 6
09G6 A 480 / 3ph 10
10G6 A 480 / 3ph 10
The voltage rating of the external fuses shall be at least equal to the input voltage of the
drives.
47
FUNCTIONAL SAFETY
