5.2 Back Panel
Controls and connections are found on the back panel of each speaker, marked as
shown.
B Bluetooth pairing button Enables Bluetooth pairing. The speakers will be ready
to pair a new device. Any Bluetooth connected device
will be disconnected.
M Master-Slave pairing
button
Re-establishes the connection between the Master and
Slave Speakers if the connection is lost.
R Factory reset button
(inside the small hole)
Resets the speakers to the factory defaults.
O Optical input port Plays audio input from a source (e.g. television*, game
console) through an optical cable (not provided).
X Auxiliary input jack Plays audio input from a source (e.g. phono stage)
through a 3.5 mm audio cable (not provided).
S Subwoofer output jack Connects a subwoofer with the speakers through an
RCA cable (not provided).
N Network port Connects the speakers to a router with a LAN cable
(not provided).

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
