KEF LSX User Manual

75
Table of ContentsSetting Up the LSXUsing the KEF Control AppPlayback and StreamingFAQ and Troubleshooting
15.2 Integration with Home Automation Control System
Drivers for integrating LSX to the most common Home Automation Control System are
available for download.
Control 4 https://www.intrinsicdev.co.uk/downloads/kef_ls50w_c4/
Crestron https://www.intrinsicdev.co.uk/downloads/kef-ls50w-for-crestron/
Elan https://www.intrinsicdev.co.uk/downloads/kef_ls50w_elan/
RTi https://www.intrinsicdev.co.uk/downloads/kef-ls50w-for-rti/
For support and information on the above drivers, please contact our
development partner Intrinsic(DEV) directly: https://www.intrinsicdev.co.uk/
Savant: Drivers for the Savant platform are embedded and downloaded as part
of the Savant software suite. Please contact your authorized Savant dealer for
information regarding integration with the Savant control platform.
Important information for integrators and developers:
• These drivers do not control streaming (handled by the app).
• LSX supports Wake On LAN (WOL)
• The following commands are available via IP Control:
1. Input Select
2. Volume +/–
3. Mute toggle

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
