9.1.2 Streaming with AirPlay 2
The speakers are ready for AirPlay 2* (Firmware 4.0 or later).
1. To stream audio through AirPlay 2, start playback on your iOS device.
2. Tap the AirPlay 2 icon ( ) at the bottom of the playback screen.
3. Select the “KEF LSX” speakers (or the name you have created for the speakers) from
the selection menu. The audio output will be played from the selected speakers.
Apple Airplay 2 also extends the speakers to become part of a multi-room wireless
music system which can be controlled with iOS devices. If you have more than one pair
of speakers connected to the same network, select the pairs for playback of the same
audio output at the same time.
*AirPlay 2 is available in:
• iPhone, iPad or iPod touch with iOS 11.4 or later
• Apple TV 4K or Apple TV (4th generation) with tvOS 11.4 or later
• Mac or PC with iTunes 12.8 or later

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
