KEF LSX User Manual

31
Table of ContentsSetting Up the LSXUsing the KEF Control AppPlayback and StreamingFAQ and Troubleshooting
8.1.3 Adjusting the Settings of the Speakers
Tap the Speaker Settings icon ( ) at the top right corner on the home screen to access
the settings menu for more configurations.
• Cable Mode
You can connect the Master and Slave Speakers with the provided inter-speaker cable
through the “To Master/Slave” connection ports on the back of the speakers.
Once the cable is connected, enable Cable Mode to disable the wireless connection.
Cable Mode is required/recommended when:
• You are performing a firmware update.
• You prefer a better resolution at 96 kHz/24 bit (wireless: 48 kHz/24 bit).
• You are experiencing audio dropouts due to interference.
• Inverse L/R Speakers
Enable this setting to change the master channel to the left (L) channel.
• Standby Mode
This determines how long (20 or 60 min) the speakers will remain idle before
automatically entering Standby Mode. If “never” is selected, the speakers must be
manually turned off.

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
