KEF LSX User Manual

14
Table of ContentsSetting Up the LSXUsing the KEF Control AppPlayback and StreamingFAQ and Troubleshooting
C USB power port
(5 V 2 A)
Charges Compatible Personal Assistant Devices and
mobile devices. Charging is not available when the
speakers are in Standby Mode.
T To Master/Slave
connection port
Connects to the Master/Slave Speaker with the inter-
speaker cable.
A AC input connector Connects the speakers to the power source with the
power cables.
*Make sure your television is set to output digital audio in PCM format. Refer to the user manual of your
television for details.
A threaded hole (¼–20 UNC) can be found on the underside of each speaker
for stands or wall mounting. See chapter “Installing the Speakers”.
5.3 Remote Control
Source button
Volume up button
Play/pause button
Next button
On/off button
Volume down button
Mute button
Previous button
Remove the insulation tab from the battery compartment before use.

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
