7.4.2 Android and iOS (Non Airplay 2) Method

Airplay 2 is available from firmware version 4.0. After firmware upgrade, iOS

users should follow the chapter "iOS (Airplay 2) Method" to perform the setup.

1. To connect LSX to your network, open the KEF Control app on your device. Select

“KEF LSX” from the selection menu and then tap “Next”.

2. Connect the power cables to the AC input connectors at the back of the speakers.

Then tap “Next”.

3. The LED indicator on the Master Speaker will ash orange and white, indicating that

the speakers are ready for connection. Tap “Next”.

1. 2. 3.

4. Tap the Home button of your device.

5. Open the “Settings” app of your device.

6. Select “Wi-Fi”.

7. Select “LSX_XXX” from the available networks.

Other manuals for KEF LSX

Questions and Answers:

Need help?

Do you have a question about the KEF LSX and is the answer not in the manual?

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
