KEF LSX User Manual

44
Table of ContentsSetting Up the LSXUsing the KEF Control AppPlayback and StreamingFAQ and Troubleshooting
• Adding Tracks to a Playlist
1. From a list of tracks or from the playback screen, tap the option icon (
…
) on the
right and then select “Add to Playlist”.
2. Select the playlist you want the track to add to.
Depending on your selections, you can also add all tracks from an artist or all
tracks from an album to the playlist.
• Editing a Playlist
1. Tap “Playlists” from the main menu.
2. Tap the playlist to be edited.
3. Tap the option icon (
…
) at the top right corner.
4. Tap “Edit”.
5. To remove a track from the playlist, select the track by tapping in the circle and
then tap the dustbin icon ( ).
6. To edit the playback sequence, press and hold the three bars icon ( ) on the
right hand side and then drag the track up or down the playlist.

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
