Keithley 2000 Calibration Manual

Recommended test equipment
Table 1-1 summarizes recommended verification equipment. Use the Fluke Model 5700A
Calibrator (or the equivalent) to verify Model 2000 Multimeter measurement accuracy.
You can use alternate equipment as long as that equipment has specifications at least as good
as those listed in Table 1-1. Keep in mind, however, that the calibrator will add to the uncertainty
of each measurement. Table 1-1 lists the uncertainties of the recommended Fluke 5700A at each
source value.
Table 1-1
Recommended verification equipment
Fluke 5700A Calibrator:
DC voltage
AC voltage
(1kHz, 50kHz)*
DC current
AC current
(1kHz)
Resistance
100mV: ±14ppm
1.0V: ±7ppm
10V: ±5ppm
100V: ±7ppm
1000V: ±9ppm
100mV: ±200ppm
1.0V: ±82ppm
10V: ±82ppm
100V: ±90ppm
700V: ±85ppm
10mA: ±60ppm
100mA: ±70ppm
1A: ±110ppm
2.2A: ±94ppm
1A: ±690ppm
2.2A: ±682ppm
100
Ω : ±17ppm
1k
Ω : ±12ppm
10k
Ω : ±11ppm
100k
Ω : ±13ppm
1M
Ω : ±18ppm
10M
Ω : ±37ppm
100M
Ω : ±120ppm
Fluke 5725A Amplifier:
AC Voltage, 50kHz: 700V, ±375ppm
*1kHz specifications shown. 5725A amplifier required to source 700V @ 50kHz.
90-day, 23°C ±5°C specifications shown.
NOTE: The Fluke 5725A amplifier is necessary only if you wish to verify the 750V AC range at 50kHz. Verifica-
tion at 220V, 50kHz using only the 5700A calibrator is adequate for most applications.
1-4 Performance Verification

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
