Keithley 2000 Calibration Manual

JMM 8/8/01
Rev. E
2000 6½-Digit Multimeter Specifications
DC CHARACTERISTICS
CONDITIONS: MED (1 PLC)
1
or SLOW (10 PLC) ACCURACY: ±(ppm of reading + ppm of range)
or MED (1 PLC) with filter of 10 (ppm = parts per million) (e.g., 10ppm = 0.001%)
Function Range Resolution
Test Current Or
Burden Voltage
(±5%)
Input
Resistance
24 Hour
14
23°C ±1°
90 Day
23°C ±5°
1 Year
23°C ±5°
Temperature
Coefficient
0°-18°C &
28°-50°C
Voltage
100.0000 mV 0.1 µV
>10 GΩ
30 + 30 40 + 35 50 + 35 2 + 6
1.000000 V 1.0 µV
>10 GΩ
15 + 6 25 + 7 30 + 7 2 + 1
10.00000 V 10 µV
>10 GΩ
15 + 4 20 + 5 30 + 5 2 + 1
100.0000 V 100 µV
10 MΩ
±1%
15 + 6 30 + 6 45 + 6 5 + 1
1000.000 V
9
1mV
10 ΜΩ
±1%
20 + 6 35 + 6 45 + 6 5 + 1
Resistance
15
100.0000 Ω 100 µΩ
1 mA 30 + 30 80 + 40 100 + 40 8 + 6
1.000000 kΩ 1mΩ
1mA 20 + 6 80 + 10 100 + 10 8 + 1
10.00000 kΩ 10 mΩ
100 µA 20 + 6 80 + 10 100 + 10 8 + 1
100.0000 kΩ 100 mΩ
10 µA 20 + 6 80 + 10 100 + 10 8 + 1
1.000000 MΩ
16
1 Ω
10 µA 20 + 6 80 + 10 100 + 10 8 + 1
10.00000 MΩ
11, 16
10 Ω 700 nA // 10M Ω
150 + 6 200 + 10 400 + 10 70 + 1
100.0000 MΩ
11, 16
100 Ω 700 nA // 10M Ω
800 + 30 1500 + 30 1500 + 30 385 + 1
Current
10.00000 mA 10 nA < 0.15 V 60 + 30 300 + 80 500 + 80 50 + 5
100.0000 mA 100 nA < 0.03 V 100 + 300 300 + 800 500 + 800 50 + 50
1.000000 A 1 µA < 0.3 V 200 + 30 500 + 80 800 + 80 50 + 5
3.00000 A 10 µA < 1 V 1000 + 15 1200 + 40 1200 + 40 50 + 5
Continuity 2W
1 kΩ 100 mΩ
1 mA 40 + 100 100 + 100 120 + 100 8 + 1
Diode Test
3.00000 V 10 µV 1 mA 20 + 6 30 + 7 40 + 7 8 + 1
10.00000 V 10 µV 100 µA 20 + 6 30 + 7 40 + 7 8 + 1
10.00000 V 10 µV 10 µA 20 + 6 30 + 7 40 + 7 8 + 1

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
