Keithley 2000 Calibration Manual

JMM 8/8/01
Rev. E
2000 6½-Digit Multimeter Specifications
TRIGGERING AND MEMORY
READING HOLD SENSITIVITY:
0.01%, 0.1%, 1%, or 10% of reading.
TRIGGER DELAY:
0 to 99 hrs (1ms step size).
EXTERNAL TRIGGER LATENCY:
200µs + <300µs jitter with autozero
off, trigger delay = 0.
MEMORY:
1024 readings.
MATH FUNCTIONS
Rel, Min/Max/Average/StdDev (of stored reading), dB, dBm, Limit Test, %,
and mX + b with user defined units displayed.
dBm REFERENCE RESISTANCES:
1 to 9999Ω in 1Ω increments.
STANDARD PROGRAMMING LANGUAGES
SCPI (Standard Commands for Programmable Instruments)
Keithley 196/199
Fluke 8840A. 8842A
REMOTE INTERFACE
GPIB (IEEE-488.1, IEEE-488.2) and RS-232C.
GENERAL
POWER SUPPLY:
100V / 120V / 220V / 240V ±10%.
LINE FREQUENCY:
45Hz to 66Hz and 360Hz to
440Hz, automatically sensed at power-up.
POWER CONSUMPTION:
22 VA.
OPERATING ENVIRONMENT:
Specified for 0°C to
50°C. Specified to 80% R.H. at 35°C.
STORAGE ENVIRONMENT:
-40°C to 70°C.
WARRANTY:
3 years.
EMC:
Complies with European Union Directive
89/336/EEC, EN61326-1.
SAFETY:
Conforms to European Union Directive
73/23/EEC EN61010-1, CAT II.
VIBRATION:
MIL-PRF-28800F Class 3 Random.
WARMUP:
1 hour to rated accuracy.
DIMENSIONS: Rack Mounting:
89mm high × 213mm
wide × 370mm deep (3½ in. × 8⅜ in. × 14
9
/
16
in.).
Bench Configuration (with handle and feet):
104mm
high × 238mm wide × 370mm deep (4⅛ in. × 9⅜ in. ×
14
9
/
16
in.).
NET WEIGHT:
2.9kg (6.3 lbs).
SHIPPING WEIGHT:
5kg (11 lbs).
VOLT HERTZ PRODUCT:
<8 × 10
7
V·Hz.
Specifications are subject to change without notice.

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
