D-4 Instrument Control

Turning on the output

Use OUTP ON and OUTP OFF to turn the output on and off respectively.

Requesting readings

To trigger and request a reading, ﬁrst send the :READ? query, then address the instrument to talk

in the usual manner. The type of readings sent will depend on the selected reading mode.

Basic control program

Use the program below to send commands to the unit. To request a reading, type in “:READ?” at

the command prompt, or type in “Q” to exit the program. See Appendix C for information on com-

puter hardware and software requirements.

Program D-1

Basic control programming

' Program to send basic commands to 2303. Primary address =16.

OPEN "IEEE" FOR OUTPUT AS #1 ' Open IEEE-488 output path.

OPEN "IEEE" FOR INPUT AS #2 ' Open IEEE-488 input path.

PRINT #1, "INTERM CRLF" ' Set input terminator.

PRINT #1, "OUTTERM LF" ' Set output terminator.

PRINT #1, "REMOTE 16" ' Put 2303 in remote.

CLS

Start: PRINT "Command: "; ' Print command prompt.

LINE INPUT Cmd$ ' Input command string.

IF Cmd$ = "Q" THEN GOTO Quit ' Check for Q to quit.

PRINT #1, "OUTPUT 16;"; Cmd$ ' Send command to unit.

IF Cmd$ = ":READ?" THEN ' Check for :READ? query.

PRINT #1, "ENTER 16" ' Address to talk.

LINE INPUT #2, Reading$ ' Input reading string.

PRINT Reading$

END IF

GOTO Start

Quit: PRINT #1, "LOCAL 16" ' Got to local.

END
