4-14 Replaceable Parts
Model 2303B parts lists
Table 4-5
Model 2303B digital board lists
Circuit designation Description Keithley part no.
C100,111,117,122,124,128,151-153,213 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C101,C102,C105,C115 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C106,C150,C265 CAP, 1000PF, 10%, 50V, MONO CERAMIC C-452-1000P
C107,C108,C129,C133 CAP, 22U 20%, 25V, TANTALUM C-535-22
C109,C184 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C110,C112,C116,C120,C130,C141,C161,
C162
CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C113 CAP, 68PF, 10%, 100V, CERAMIC C-451-68P
C114,C145 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C118,C138 CAP, 2200P, 1%, 50V, CERAMIC C-532-2200P
C119,C148,C156 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C123,134,269,139,147 CAP, 10UF, 20%, 25V, TANTALUM C-440-10
C125,126,274,149,154,155,196,275 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C127,C146 CAP, 470P, 10%, 100V, CERAMIC C-451-470P
C135,C266 CAP, 2.2U, 10%, 50V TANTALUM C-563-2.2
C136,157,165,189,193,282,204,121,103 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C143 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
C158 CAP, .01uF, 20%, 50V, CERAMIC C-418-.01
C159 CAP, .022UF, 10%, 50V, CERAMIC C-491-.022
C160,142,166,197,264,276 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C163,C190,C195 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C167 CAP, 4700PF, 20%, 50V, CERAMIC C-418-4700P
C171,C188 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C173,C183 CAP, 2200P, 10%, 100V, CERAMIC C-430-2200P
C179,C185,C212,C214 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C181 CAP, 220UF, ±20%, 50V, ALUM ELEC C-507-220
C191,C192,C168 CAP, 15P, 1%, 100V, CERAMIC C-512-15P
C194 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C215-222,225-230,238,241,244,246-248 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C223,C224,C273 CAP, .47U, 20%, 25V C-520-.47
C233,C234,C235 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C236,C239,C277 CAP, 1UF, 20%, 35V, TANTALUM C-494-1
C237,C240 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C245,C249,C258,C164 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
To Next Page
