Calibration 2-13
* Step numbers correspond to :CAL:PROT:STEP command numbers.
** Factory default display values.
Step 3: Enter calibration dates, and save calibration
1. After completing all calibration steps, the unit will prompt if you wish to save
calibration:
CALIBRATE UNIT
Save Cal Data YES
2. To save new calibration constants, select YES, then press ENTER. If, on the other hand,
you wish to exit calibration without saving new calibration constants, select NO, then
press ENTER. In that case, the unit will revert to prior calibration constants.
3. The unit will then prompt you to enter the calibration date:
CALIBRATE UNIT
Cal Date 02/01/98
4. Using the edit keys, set the calibration date to today’s date, then press ENTER. The unit
will display the following:
CALIBRATE UNIT
EXITING CAL
5. Press ENTER to complete the calibration procedure and return to the menu display.
Calibration is now complete.
Table 2-3
Model 2303-PJ front panel calibration summary
Step* Description Nominal calibration signal** Test connections
0 Output 14V 14V Figure 2-2
1 Full-scale output voltage 14V Figure 2-2
2 Full-scale measure 14V Figure 2-2
3 Full-scale DVM 14V Figure 2-2
4 5A range output current 1.9A Figure 2-3
5 5A current limit 1.9A Figure 2-3
6 5A measure 1.9A Figure 2-3
7 500mA range output current 450mA Figure 2-5
8 500mA measure 450mA Figure 2-5
