Keithley 2303 - Calibration Step Summary

Calibration Reference B-5
Example
:CAL:PROT:SAVE
Save calibration constants
:STEP
(:CALibration:PROTected:STEP<n>)
Purpose To perform various calibration steps.
Format
:cal:prot:step<n>
Parameters See Table B-2.
Description The :CAL:PROT:STEP<n> command performs calibration at the various
points listed in Table B-2. See
Section 2 for details on test equipment and
connections.
Note Calibration steps must be performed in the order listed in Table B-2, or an
error will occur.
Example
:CAL:PROT:STEP0 14
Perform cal step 0 (full-scale output).
Table B-2
Calibration step summary
Command Description
:CALibration Calibration subsystem.
:PROTected Cal commands protected by password.
:STEP0 <nrf> Output full-scale voltage (14V).
:STEP1 <nrf> Calibrate output voltage setting using external DMM
reading.
:STEP2 <nrf> Calibrate voltage measuring using external DMM reading.
:STEP3 Perform DVM input full-scale (14V) cal.
:STEP4 <nrf> Output current (1.9A) for 5A full-scale cal.
:STEP5 <nrf> Calibrate output current limit using calculated current.
:STEP6 <nrf> Calibrate 5A measurement range using calculated current.
:STEP7 Output 5mA (500mA, Model 2303-PJ) nominal current.
:STEP8 <nrf> Calibrate 5mA (500mA, Model 2303-PJ) measurement
range using calculated current.
