Keithley 2303 Service Manual

4-8 Replaceable Parts
Table 4-2
Models 2303 and 2303-PJ analog board parts list
Circuit designation Description Keithley part no.
C301,308,310,312,313,320,325,329,333,337 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C302,C489,C506 CAP, 1UF, 20%, 50V, TANTALUM C-431-1
C303,C309 CAP, 7.5P, 10%, 100V, CERAMIC C-452-7.5P
C304,488,307,315,317,321,328,338,339,346 CAP, .1UF, 20%,50V, CERAMIC C-418-.1
C314,335,336,371,372,377,378 CAP, 47UF, 20%, 100V, ALUM ELEC C-521-47
C319,C498,C306,C330 CAP, 4.7PF, 5%, 50V, MONO-CERAMIC C-452-4.7P
C322,331,359-361,374,343,434,508 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C323,C416,C422 CAP, 22U, 20%, 25V, TANTALUM C-535-22
C326,C404,C487 CAP, 1UF, 20%, 35V, TANTALUM C-494-1
C334 CAP, 100UF, 20%, 25V, ALUM ELEC C-413-100
C347,C478 CAP, 470U, 20%, 25V, ALUM ELEC C-478-470
C348,351,366,417,486 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C352,354,355,358,373,379,382,384,515-519 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C353,C357,C367 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C356,C499,C500 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C362,C509 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C363,C480,C481 CAP, 3300P, 10%, 500V, CERAMIC C-497-3300P
C365 CAP, 2200P, 1%, 50V, CERAMIC C-532-2200P
C368,C369 CAP, 100UF, 20%, 16V, TANTALUM C-504-100
C370,C305 CAP, 2.2U, 10%, 50V, TANTALUM C-563-2.2
C376 CAP, .022UF, 10%, 50V, CERAMIC C-491-.022
C390,407,414,415,423,424,494,495,435-437 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C392,C393,C350,C491 CAP, .01, 5%, 50V, NPO C-514-.01
C394,C396 CAP, 1500P, 20%, 700V C-560-1500P
C395 CAP, 10U, 20%, 35V, ALUMINUM C-562-10
C402,C397 CAP, 47PF, 10%, 100V, CERAMIC C-451-47P
C405,C421 CAP, .033U, 10%, 50V, CERAMIC C-491-.033
C406,C410 CAPACITOR C-570-470
C426-429,344,345,479,482,483 CAPACITOR SMT C-568-2200P
C438-C477,C505 CAP, 1U, 10%, 50V, CERAMIC C-564-1
C490 CAP, 100P, 10%, 100V CERAMIC C-451-100P
C492,C493 CAP, 390P, 10%, 100V, CERAMIC C-451-390P
C497,C514 CAP, 150PF, 5%, 100V,CERAMIC C-465-150P
C501,502,503,419,504,507,510,511,420 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C512,C513,C380,C385,C318,C364 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
CR302,CR322,CR330,CR332,CR318 DIODE, SWITCHING, MMSD914T19 RF-112
