1-14 Performance Verification
2. Select the DMM DC volts function, and enable auto-ranging.
3. Enable the Model 2303 DVM input.
4. Turn on the Model 2303 source output.
5. Verify digital voltmeter input accuracy for each of the voltages listed in Table 1-8. For
each test point:
• Set the voltage to the indicated value as measured by the digital multimeter.
• Set compliance to 3A.
• Allow the reading to settle.
• Verify that the Model 2303 voltage reading is within the limits given in the table.
* As measured by digital multimeter. See procedure.
Table 1-8
Digital voltmeter input accuracy limits
Model 2303 output
voltage setting*
Digital voltmeter input reading limits
(1 Year, 18°C-28°C)
14.00V 13.990 to 14.010V
3.00V 2.996V to 3.004V
