4-10 Replaceable Parts
R315,372,314,492,415,441,458-460 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R320,R444 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R321,R503 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R322,R489 RES, 8.06K, 1%, .1W, THICK FILM R-418-8.06K
R325 RES, 10, 10%, 100MW, THICK FILM R-418-10
R326 RES, 14K, 1%, 125MW, METAL FILM R-391-14K
R329-332,357,358,360,361,378,379,390,391 RES, 10K, 5%, 250MW, METAL FILM R-376-10K
R333,R335,R349,R355 RES, 20K, 5%, 250MW, METAL FILM R-376-20K
R337,R343,R344,R456,R457,R476,R477,
R499
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R340,R341 RES, 1K, 5% 250MW, METAL FILM R-376-1K
R342 RES, 24.3, 1%, 100MW, THICK FILM R-418-24.3
R345,R346,R347,R348 RES, 560, 5%, 250MW, METAL FILM R-376-560
R350,368,426-428,435,328,339 RES, 10,5%, 125MW, METAL FILM R-375-10
R352,R478,R491 RES, 20K, 1%, 100MW, THICK FILM R-418-20K
R353,354,461,473,495,496 RES, 475, 1%, 100MW, THICK FILM R-418-475
R363,R370 RES, 8,98K, .1%, .125W, THIN FILM R-456-8.98K
R364,R369 RES, 1K, .1%, .125W, THIN FILM R-456-1K
R373,R374,R387,R392 RES, 20K, 1%, 125MW, METAL FILM R-391-20K
R375,R377 RES, 1K, 5%, 1W 200V, THICK FILM R-437-1K
R376 RES, 100, .1%, 1/2W, METAL FILM R-169-100*
R376 RES, 1, 1%, 1W, METAL FILM R-487-1**
R383,R385,R386,R388 RES, 49.9K, 1%, 125MW, METAL FILM R-391-2.87K
R384 RES, 4.02K, 1%, 100MW, THICK FILM R-418-4.02K
R393,R394 RES, .02, 1.5W, 1% R-468-.02
R397 RES, 357, 1%, 100MW, THICK FILM R-418-357
R399,R400,R488 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R401 RES, 301, 1%, 100MW, THICK FILM R-418-301
R411,413,417,419,474,483 RES, 100, 1%, 100MW, THICK FILM R-418-100
R421,R422,R480 RES, 200K, 1%, 125MW, METAL FILM R-391-200K
R429,433,434,436,356,371 RES, 7.5, 5%, .5W, THICK FILM R-469-7.5
R432 RES, 3.01K, 1%, 100MW, THICK FILM R-418-3.01K
R455 RES, .1, 1%, 3W R-475-.1
* Model 2303 only.
** Model 2303-PJ only.
Table 4-2 (continued)
Models 2303 and 2303-PJ analog board parts list
Circuit designation Description Keithley part no.
