Keithley 3730 User Manual

Series 3700
System Switch/Multimeter User's Manual Section 2:
Using the Front Panel
Document Number: 3700S
-900-01 Rev. A / August 2007 2
-9
 VIEW: This menu item shows the channels associated with the pattern. Note that if no
patterns exist in the system when the PATT key is pressed, then this will be the only
menu item displayed in the PATTERN ACTION MENU. Related ICL command:
channel.pattern.getimage
 DELETE: This menu item deletes a channel pattern. Related ICL command:
channel.pattern.delete
 RESET: This menu item resets channel pattern aspects of the system to factory default
settings. Resetting a channel pattern will cause each channel and backplane relay of the
pattern image to be reset back to factory default settings. Also, the pattern will be deleted
because resetting a channel causes any patterns that contain a channel being reset will
be deleted. Related ICL command: channel.reset
If patterns (or a pattern) have already been created, pressing this key once will allow you to
scroll through and select a pattern. Pressing this key a second time opens the PATTERN
ACTION MENU (as described above).
PATT key configuration
Pressing the CONFIG key and then the PATT key opens the PATTERN ATTRibute MENU. This
menu contains the following item:
 DMM_CONFIG: This menu item sets the DMM configuration associated with the
channels specified. Related ICL command: dmm.setconfig
SLOT key
Press this key to display installed card(s) and instrument information, as well as main system
information. The information displayed includes firmware revisions of both main and installed
components. After pressing this key, scroll through all available instruments, including the
internal DMM.
SCAN key
If a scan list is present, this key opens the SCAN ACTION MENU that contains the following
menu items:
NOTE Use the INSERT key to create and add the present active channel to the scan list.
 EXECUTE: This menu item runs the scan. Related ICL command: scan.execute
 CREATE: This menu item displays following message: Use <INSERT> key
 LIST: This menu item displays the scan list (turn the wheel to scroll). Related ICL
command: scan.list
 CLEAR: This menu item clears the scan list. Related ICL command: scan.create (send
with an empty string)
 RESET: This menu item resets the scan settings to factory default values. Related ICL
command: scan.reset
