Keithley 6517 - Page 100

Replaceable Parts
7-8
R301,302,424,425,510,513
R303,306,310,321
R304,308,314,316,441,463
R305,307,312,318,494,495
R309,334,475-477
R313,335
R315,317,319,320,322,329,332
R323,415,508,492,493,433,458
R324
R336-339
R346
R347,459-462,502,240,217
R354
R358-360,397,398,414,448
R361
R362
R364,370,598
R367
R368
R369
R371
R373-389,449-453, 464-470, 527
R390-392,403,404,406,407,412
R396,523,504,416
R411
R413,525
R426,480,481
R428,429
R430,440
R431
R432
R434,417
R436
R438,439,443
R442
R490
R496,497
R501,506
R505
R507
R522
R524
R526
R530,531
R595
RES, 200K, 5%, 250MW, METAL FILM (1210)
RES, 2.21K, 1%, 100MW, THICK FILM (0805)
RES, 4.02K, 1%, 100MW, THICK FILM (0805)
RES, 100, 1%, 100MW, THICK FILM (0805)
RES, 100K, 1%, 100MW, THICK FILM (0805)
RES, 75K, 1%, 100MW, THICK FILM (0805)
RES, 10M, 10%, 525MW, THICK FILM (1505)
RES, 499, 1%, 100MW, THICK FILM (0805)
RES, 249, 1%, 100MW, THICK FILM (0805)
RES, 2M, 1%, 100MW, THICK FILM (0805)
RES, 806, 1%, 100MW, THICK FILM (0805)
RES, 1M, 1%, 100MW, THICK FILM (0805)
RES, 10M, 2%, 1W, 1500VDC, THICK FILM
RES, 10M, 10%, 525MW, THICK FILM (1505)
RES, 48.1K, .1%, 1/10W, METAL FILM
RES, 487K, .1%, 1/10W, METAL FILM
RES, 7.32, 1%, 100MW, THICK FILM (0805)
RES, 59K, 1%, 100MW, THICK FILM (0805)
RES, 82.5, 1%, 100MW, THICK FILM (0805)
RES, 66.5, 1%, 100MW, THICK FILM (0805)
THICK FILM
RES, 470K, 5%, 250MW, METAL FILM (1210)
RES, 10K, 1%, 100MW, THICK FILM (0805)
RES, 2K, 1%, 100MW, THICK FILM (0805)
RES, 4T, 10%, 1W, 1500VDC, THICK FILM
RES, 249K, 1%, 100MW, THICK FILM (0805)
RES, 10, 10%, 100MW, THICK FILM (0805)
RES, 24.3, 1%, 100MW, THICK FILM (0805)
RES, 402K, 1%, 100MW, THICK FILM (0805)
RES, 1G, 10%, HIGH ALUMINA
RES, 1T, 10%, 1W, 1500VDC, THICK FILM
RES, 10K, 1%, 100MW, THICK FILM (0805)
RES, 255K, 1%, 100MW, THICK FILM (0805)
RES, 3K, 1%, 750MW, FILM
RES, 150K, 5%, 250MW, METAL FILM (1210)
RES, 30.1K, 1%, 100MW, THICK FILM (0805)
RES, 49.9, 1%, 100MW, THICK FILM (0805)
RES, 392, 1%, 100MW, THICK FILM (0805)
RES, 80.6K, 1%, 100MW, THIN FILM (0805)
RES, 24.9K, 1%, 100MW, THIN FILM (0805)
RES, 3.01K, 1%, 100MW, THICK FILM (0805)
RES, 80.6K, 1%, 100MW, THICK FILM (0805)
RES, 1K, 5%, 250MW, METAL FILM (1210)
RES, 1M, 5%, 250MW, METAL FILM (1210)
RES, 33.2, 1%, 100MW, THICK FILM (0805)
R-376-200K
R-418-2.21K
R-418-4.02K
R-418-100
R-418-100K
R-418-75K
R-430-10M
R-418-499
R-418-249
R-418-2M
R-418-806
R-418-1M
R-417-10M
R-430-10M
R-263-48.1K
R-263-487K
R-418-7.32
R-418-59K
R-418-82.5
R-418-66.5
TF-248
R-376-470K
R-418-10K
R-418-2K
R-429-4T
R-418-249K
R-418-10
R-418-24.3
R-418-402K
R-435-1G
R-429-1T
R-418-10K
R-418-255K
R-436-3K
R-376-150K
R-418-30.1K
R-418-49.9
R-418-392
R-438-80.6K
R-438-24.9K
R-418-3.01K
R-418-80.6K
R-376-1K
R-376-1M
R-418-33.2
Table 7-3
Model 6517A analog board, parts list (cont.)
Circuit designation Description
Keithley part
number
