Calibration
2-3
Table 2-1
Recommended calibration equipment
Mfg. Model Description Specifications*
Fluke 5700A Calibrator ±5ppm basic uncertainty
1
DC Voltage:
1.9V: ±7ppm
19V: ±5ppm
190V: ±7ppm
DC current:
19µA: ±576ppm
190µA: ±103ppm
1.9mA: ±55ppm
19mA: ±55ppm
Keithley 5156 Electrometer Calibration Standard 100M
Ω
2
1G
Ω
10G
Ω
100G
Ω
1nF
100nF
Keithley 2001 Multimeter 1000V range: ±47ppm
3
200V range: ±41ppm
Keithley 8607 Dual banana plug cable
Keithley 4801 Low-noise coax cable
Keithley 7078-TRX-BNC Triax-to BNC adapter
BNC to dual banana plug adapter
Keithley 237-ALG-2 Triax to alligator clips cable*
Keithley CAP-31 Triax shielding cap
Banana plugs to clip leads
2, 1 in. lengths of solid #20AWG wire
Omega CL-307-K Type K thermocouple simulator/calibrator 0°C (0mV), 100°C (4.095mV) ±0.04%
1. 90-day calibrator specifications shown include total absolute uncertainty at specified output.
2. Nominal values for calibration standards shown. Alternate standards may be used if those standards are characterized to uncertainty at least four
times better than equivalent Model 6517A specifications.
3. 1-year multimeter specifications are for full-range input.
*Short red and black clips together to make triax short.
