Keithley 6517 - Table

Replaceable Parts
7-4
R840
R841
R842
R843
R844
R845
R847
R848,851-853
R849,855,858,865
R850
R854
R856,857
R860
R863
U800,801
U802
U803,804
U806
U807
U809
U810,811
U812
U813
Y800
RES, 40K, .1%, 1/10W, METAL FILM
RES, 57.8K, .1%, 1/10W, METAL FILM
RES, 920K, .1%, 1/10W, METAL FILM
RES, 1.2K, .1%, 1/10W, METAL FILM
RES, 4.M, .1% 1/8W, METAL FILM
RES, 2K, .1%, 1/10W, METAL FILM
RES, 3.2K, .1%, 1/10W, METAL FILM
RES, 49.9, 1%, 125mW, METAL FILM (1206)
RES, 3.01K, 1%, 125MW, METAL FILM(1206)
RES, 100, 1%, 1/8W, METAL FILM
RES, 1.62K, 1%, 1/8W, METAL FILM
RES, 10, 5%, 125MW, METAL FILM(1206)
RES, 150K, 5%, 125MW, METAL FILM (1206)
RES, 100, 1%, 125mW, METAL FILM (1206)
IC, 8 STAGE SHIFT/STORE, MC14094BD (SOIC)
IC, OP-AMP, NE5534D (SOIC)
IC, VOLT COMPARATOR, LM311M (SOIC)
IC, VOLT COMPARATOR, LM393D (SOIC)
IC, QUAD COMPARATOR, LM339D (SOIC)
IC, OP-AMP, OPA602AP
IC, OP-AMP, LT1097
IC, DUAL D-TYPE F/F, 74HC74(SOIC)
INTEGRATED CIRCUIT, OPA177GS(SOIC)
OSCILLATOR CMOS, 7.68 MHZ
R-263-40K
R-263-57.8K
R-168-920K
R-263-1.2K
R-402-4M
R-263-2K
R-263-3.2K
R-391-49.9
R-391-3.01K
R-88-100
R-88-1.62K
R-375-10
R-375-150K
R-391-100
IC-772
IC-802
IC-776
IC-775
IC-774
IC-703
IC-803
IC-773
IC-960
CR-31
Table 7-1
Model 6517A ADC board, parts list (cont.)
Circuit designation Description
Keithley part
number
