Keithley 6517 - Model 6517 A ADC Board, Parts List; Table; Table 7-1 Model 6517 A ADC Board, Parts List

Replaceable Parts
7-3
Table 7-1
Model 6517A ADC board, parts list
Circuit designation Description
Keithley part
number
ADC ASSEMBLY
CHOKE 21-030-J
DIODE, ZENER 6.4V, IN4579 (DO-7)
PROGRAM
SOCKET, 68-PIN QUAD
2001-160
CH-55
DZ-73-1
2001-802*
SO-128-68
C800-803,807,809,815,819,820
C804,805
C808,818
C812,826-829
C814,824
C817
C821
C822,823
C825
C831
CR801
P1026
Q800
Q801
Q802-806,814
Q807,809,811
Q808,813
Q810
Q812
R800,813,838
R801
R802-805
R806,827
R808,859,811,812,862
R810,820
R814
R815,829
R818,823
R819
R821,822,864
R824,830
R826
R828,861
R833-836
R837,846
R839
CAP, .1UF, 20%, 50V, CERAMIC (1206)
CAP, .1UF, 20%, 50V, CERAMIC (1206)
CAP, 1UF, 20%, 50V, CERAMIC
CAP, 10UF, 20%, 25V, TANTALUM (D7243)
CAP, 10UF, 20%, 25V, TANTALUM (D7243)
CAP, 150PF, 5%, 100V, CERAMIC (0805)
CAP, .33UF, 10%, 50V, CERAMIC (1812)
CAP, 27PF, 10%, 100V, CERAMIC (1206)
CAP, .01UF, 10%,100V, POLYPROPYLENE
CAP, 33PF, 10%, 100V, CERAMIC (1206)
DIODE, DUAL SWITCHING, BAV99L(SOT-23)
CONNECTOR, FEMALE 25 PIN
TRANS, PNP, MMBT3906L (SOT-23)
TRANS, NPN, MMBT3904 (SOT-23)
TRANS, N CHAN MOSPOW FET, 2N7000 (TO-92)
TRANS, SELECTED TG-128 (T0-92)
TRANS, N CHANNEL JFET, SELECTED J210
TRANS, N CHANNEL JFET, 5432 (TO-92)
IC, +5V REGULATOR, 78L05AC (T0-92)
RES, 100K, 5%, 125mW, METAL FILM (1206)
RES, 475, 1%, 125mW, METAL FILM (1206)
RES, 2.21K, 1%, 125mW, METAL FILM (1206)
RES, 33.2K, 1%, 125mW, METAL FILM (1206)
RES, 10K, 5%, 125MW, METAL FILM(1206)
RES, 2.7K, 5%, 125mW, METAL FILM (1206)
RES, 5.1K, 5%, 125MW, METAL FILM (1206)
RES, 82.5, 1%, 125mW, METAL FILM (1206)
RES, 2.74K, 1%, 1/8W, METAL FILM
RES, 18.7, 1%, 125mW, METAL FILM (1206)
RES, 1K, 5%, 125MW, METAL FILM(1206)
RES, 4.75K, 1%, 125mW, METAL FILM (1206)
RES, 3.92K, 1%, 125mW, METAL FILM (1206)
RES, 26.7K, 1%, 125mW, METAL FILM (1206)
RES, 1K, .1%, 1/10W, METAL FILM
RES, 19K, .1%, 1/10W, METAL FILM
RES, 100K, 5%, 125mW, METAL FILM (1206)
C-418-.1
C-418-.1
C-237-1
C-440-10
C-440-10
C-465-150P
C-464-.33
C-451-27P
C-306-.01
C-451-33P
RF-82
CS-767-25
TG-244
TG-238
TG-195
31841A
TG-167-1
TG-198
IC-603
R-375-100K
R-391-475
R-391-2.21K
R-391-33.2K
R-375-10K
R-375-2.7K
R-375-5.1K
R-391-82.5
R-88-2.74K
R-391-18.7
R-375-1K
R-391-4.75K
R-391-3.92K
R-391-26.7K
R-263-1K
R-263-19K
R-375-100K
*Order revision level.
