Keithley 6517 - Calibration Command Reference; IEEE-488 Bus Calibration Command Summary; Table; Table 3-1 IEEE-488 Bus Calibration Command Summary

Calibration Command Reference
3-2
Table 3-1
IEEE-488 bus calibration command summary
Command Description
CALibration:
PROTected:
INITiate
VZERO2
V2 <Nrf>
VN2 <Nrf>
VZERO20
V20 <Nrf>
VN20 <Nrf>
VZERO200
V200 <Nrf>
VN200 <Nrf>
AZERO20P
A20P <Nrf>
A20PCARD <Nrf>
AN20P <Nrf>
AN20PCARD <Nrf>
AZERO200P
A200P <Nrf>
A200PCARD <Nrf>
AN200P <Nrf>
AN200PCARD <Nrf>
AZERO2N
A2N <Nrf>
A2NCARD <Nrf>
AN2N <Nrf>
AN2NCARD <Nrf>
AZERO20N
A20N <Nrf>
A20NCARD <Nrf>
AN20N <Nrf>
AN20NCARD <Nrf>
AZERO200N
A200N <Nrf>
A200NCARD <Nrf>
AN200N <Nrf>
AN200NCARD <Nrf>
AZERO2U
A2U <Nrf>
A2UCARD <Nrf>
AN2U <Nrf>
AN2UCARD <Nrf>
AZERO20U
A20U <Nrf>
AN20U <Nrf>
AZERO200U
A200U <Nrf>
AN200U <Nrf>
Calibration subsystem
Commands protected by CAL switch
Required before performing ANY cal steps
2V range zero step
+2V step
-2V step
20V range zero step
+20V step
-20V step
200V range zero step
+200V step
-200V step
20pA range zero step
+20pA step
+20pA step (using cal standard)
-20pA step
-20pA step (using cal standard)
200pA range zero step
+200pA step
+200pA step (using cal standard)
-200pA step
-200pA step (using cal standard)
2nA range zero step
+2nA step
+2nA step (using cal standard)
-2nA step
-2nA step (using cal standard)
20nA range zero step
+20nA step
+20nA step (using cal standard)
-20nA step
-20nA step (using cal standard)
200nA range zero step
+200nA step
+200nA step (using cal standard)
-200nA step
-200nA step (using cal standard)
2µA range zero step
+2µA step
+2µA step (using cal standard)
-2µA step
-2µA step (using cal standard)
20µA range zero step
+20µA step
-20µA step
200µA range zero step
+200µA step
-200µA step
