Calibration Command Reference
3-13
3.4.4 Coulombs calibration commands
Purpose To calibrate coulombs function ranges.
Format See Tables 3-5 and 3-6.
Parameter See Tables 3-5 and 3-6.
Table 3-5
Coulombs function calibration commands and parameters (without calibration standard)
Range Command format* <Cal_charge> parameter limits (Q)
2nC :cal:prot:czeroa2n
:cal:prot:c2n <Cal_charge>
:cal:prot:czerob2n
:cal:prot:cn2n <Cal_charge>
None
0.95E-9 to 2.05E-9
None
-0.95E-9 to -2.05E-9
20nC :cal:prot:czeroa20n
:cal:prot:c20n <Cal_charge >
:cal:prot:czerob20n
:cal:prot:cn20n <Cal_charge>
None
9.5E-9 to 20.5E-9
None
-9.5E-9 to -20.5E-9
200nC :cal:prot:czeroa200n
:cal:prot:c200n <Cal_charge>
:cal:prot:czerob200n
:cal:prot:cn200n <Cal_charge>
None
95E-9 to 205E-9
None
-95E-9 to -205E-9
2µC :cal:prot:czeroa2u
:cal:prot:c2u <Cal_charge>
:cal:prot:czerob2u
:cal:prot:cn2u <Cal_charge>
None
0.95E-6 to 2.05E-6
None
-0.95E-6 to -2.05E-6
*Command short form shown.
