Keithley 6517 - Figure B-1 EERR? Query Response (Calibration Execution Errors)

Calibration Messages
B-6
Figure B-1
EERR? query response (calibration execution errors)
X X X X X X X X X X X X X X X X X X X X X X X X X X X X X
CAL DATA INVALID
CAL DATE SET
CAL NDUE SET
Figure B-2
VERR? query response (voltage function cal errors)
X X X X X X X X X X X X X X X X X X X X X X X
2V offset out of spec
2V pgain out of spec
2V ngain out of spec
20V offset out of spec
20V pgain out of spec
20V ngain out of spec
200V offset out of spec
200V pgain out of spec
200V ngain out of spec
Figure B-3
IERR? query response (current function cal errors)
X X
20pA offset out of spec
20pA pgain out of paper
20pA ngain out of spec
200pA offset out of spec
200pA pgain out of spec
200pA ngain out of spec
2nA offset out of spec
2nA pgain out of spec
2nA ngain out of spec
20nA offset out of spec
20nA pgain out of spec
20nA ngain out of spec
200nA offset out of spec
200nA pgain out of spec
200nA ngain out of spec
2µA offset out of spec
2µA pgain out of spec
2µA ngain out of spec
20µA offset out of spec
20µA pgain out of spec
20µA ngain out of spec
200µA offset out of spec
200µA pgain out of spec
200µA ngain out of spec
2mA offset out of spec
2mA pgain out of spec
2mA ngain out of spec
20mA offset out of spec
20mA pgain out of spec
20mA ngain out of spec
