Keithley DMM6500 User Manual

In this section:
Additional DMM6500 information ........................................... 11-1
Additional DMM6500 information
This manual has prepared you to start using your new DMM6500 6½ Digit Multimeter for your
application. For more detailed information, refer to the Keithley Instruments DMM6500 Reference
Manual.
Also see tek.com/keithley for support and additional information about the instrument. From the
website, you can access:
• The Knowledge Center, which contains the following handbooks:
 The Low Level Measurements Handbook: Precision DC Current, Voltage, and Resistance
Measurements
 Switching Handbook: A Guide to Signal Switching in Automated Test Systems
• Application notes
• Updated drivers
• Information about related products
Your local Field Applications Engineer can help you with product selection, configuration, and usage.
Check the website for contact information.
Section 11
Next steps

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
