Keithley DMM6500 User Manual

DMM6500
6½ Digit Multimeter User's Manual Section 4: Making basic front-
panel measurements
DMM6500-900-01Rev. A / April 2018 4-5
When you are using the FRONT terminals to make measurements, the Channel column of the
reading table displays "Front." If you are using the REAR terminals, the Channel column displays
"Rear." If you are using a card, the Channel column displays the channel number.
3. To display data for a different reading buffer, select the buffer.
4. To view details for a specific data point, swipe the table up or down and select the data point to
view the Reading Details. If there are many data points, select an area on the reading preview
graph in the upper right corner of the screen to get closer to the data you want, and then scroll to
the data point.
Press the HOME key to return to the Home screen.

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
