Flexlite GX
Operating manual - EN
3. Insert the retainer cone onto the wire liner and push in place.
4. Place the sleeve nut on the wire liner and secure it in place. Tighten to 12 Nm torque.
Installing sleeve assembly and cutting wire liner (Kemppi connector:series 8 welding guns)
The method is the same for both gas- and water-cooled welding guns, except for the additional sealing ring with the below-
mentioned models.
1. Temporarily remove the end cap from the long sleeve nut.
2. Insert the retainer cone and sleeve nut (without end cap) on the wire liner and secure them in place. Tighten to 12
Nm torque.
All series 8 Flexlite GX models (Kemppi connector) include a longer wire liner sleeve. The series 8 GMN, WS and 608W
models include also an additional sealing ring (*):
© Kemppi
15
1921390 / 2310
