Flexlite GX
Operating manual - EN
2. Insert the retainer cone and sleeve nut (without the end cap) on the wire liner and secure them in place. Tighten to
12 Nm torque.
Series 8 Flexlite GX models (Kemppi connector) include a longer wire liner sleeve. The series 8 GMN, WS and 608W
models include also an additional sealing ring (*):
3. Cut the wire liner leaving 1-2 mm of excess liner measured from the sleeve nut end. Use side cutting pliers for cut-
ting.
4. File the end of the liner.
Don't leave any rough, inward edges that could potentially damage the filler wire.
© Kemppi
20
1921390 / 2310
