Flexlite GX
Operating manual - EN
3. File the end of the liner.
Don't leave any rough, inward edges that could potentially damage the filler wire.
4. Insert the retainer cone onto the wire liner and push it in place.
5. Place the sleeve nut on the wire liner and secure it in place. Tighten to 12 Nm torque.
Installing sleeve assembly and cutting wire liner (Kemppi connector: series 8 welding guns)
The method is the same for both gas- and water-cooled welding guns, except for the additional sealing ring with the below-
mentioned models.
1. Temporarily remove the end cap from the long sleeve nut.
© Kemppi
19
1921390 / 2310
