MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
MicroTack spot count: 1 ... 5, Endless (Default = 1)
Arc force: -10 ... +10 , step 1 (Default = 0)
Hot start: -10 ... +10 , step 1 (Default = 0)
VRD: OFF / ON (Default = OFF)
>> In AU VRD version: Default ON, OFF disabled.
>> VRD (Voltage Reduction Device).
MMA Antifreeze: OFF / ON (Default = ON)
HF spark force: 50 % ... 110 %, Step 1 % (Default 100 %)
TIG antifreeze: OFF / ON (Default = OFF)
Remote mode: OFF / Remote / Torch (Default = OFF)
Remote control min: Min = “Current limit min”, Max = “Current limit max”
Remote control max: Min = “Current limit min”, Max = “Current limit max”
Wireless remote: Cancel / Start (Start pairing)
Water cooler: OFF / Auto / ON (Default: Auto)
Weld data time: OFF / 1 s ... 10 s, step 1 s (Default = 5 s)
Display off: 5 min ... 120 min, step 1 min (Default = 5 min)
Date: Date setting (DD/MM/YYYY)
>> Set the day by pressing and turning the control knob. Once the day is set, press the control knob button to
set the month etc.
Time: Time setting (HH:MM)
>> Set the hour by pressing and turning the control knob (use 24 h format). Once the hour is set, press the con-
trol knob button to set the minutes.
Language: Select language from the list
Time counter: Total arc time and power on time
Time counter (since date): Total arc time and power on time since last reset
Reset counter: Time counter reset
4T trigger logic:4T MLOG / 4T LOG / 4T LOG+ (Default = 4T MLOG)
Advanced settings (hidden in standard view):
Current limit min: TIG: 2 A / MMA: 8 A, step 1 A *
Current limit max: TIG: power source's nominal value / MMA: power source's max. MMA current, step 1 A *
Balance min: -99 % ... 0 % (Default = -60 %)
Balance max: 0 % ... 20 % (Default = 0 %)
Lift TIG current:5 A ... 40 A / Auto (Default = Auto)
Cooler flow watch: OFF / ON (Default = ON)
Positive ignition current: 30 % ... 150 % / Auto, step 1 % (Default = Auto)
Negative ignition current (AC/DC): 100 % ... 300 % / Auto, Step 1 % (Default = Auto)
Ignition current (DC): 100 % ... 300 % / Auto, step 1 % (Default = Auto)
Positive ignition time: 0 ms ... 50 ms / Auto, step 10 ms (Default = Auto)
Negative ignition time (AC/DC): 0 ms ... 950 ms / Auto, step 10 ms (Default = Auto)
© Kemppi
33/77 1920900 / 1939
