MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
Ignition time (DC): 0 ms ... 950 ms / Auto, step 10 ms (Default = Auto)
Slight upslope: OFF / ON (Default = OFF)
Startup level:5 % ... 40 %, step 1 % (Default = 10 %)
Downslope cut level: 5 % ... 40 %, step 1 % (Default = 10 %)
2T downslope cut: OFF / ON (Default = OFF)
Nonlinear downslope: 0 % ... 50 %, step 1 % (Default = 0 %)
Current freezing: OFF / ON (Default = OFF)
AC phase swap current: 5 A ... 20 A / Auto
Info:Machine type, serial number
Software version:Power source and control panel software version number
Factory reset: Cancel / Reset (Default = Cancel)
>> Resets to TIG, DC-, 50 A, HF, Pulse OFF (other values as per default).
>> Once the factory reset is complete, the power source must be restarted manually.
* Current range adjustable by welder in TIG welding:
• 2 A ... 130 A, 1 A step (MasterTig 235, limited supply mode)
• 2 A ... 235 A, 1 A step (MasterTig 235)
• 2 A ... 305 A, 1 A step (MasterTig 325, 335)
• Default = 3 A ... Nominal value of the power source.
* Current range adjustable by welder in MMA welding:
• 8 A ... 85 A, 1 A step (MasterTig 235, limited supply mode)
• 8 A ... 185 A, 1 A step (MasterTig 235)
• 8 A ... 255 A, 1 A step (MasterTig 325, 335)
• Default = 10 A ... MMA maximum current of the power source.
"Welding processes and features" on page67
