Kemppi MasterTig 535ACDC User Manual

MasterTig 535ACDC
Operating manual - EN
2.9 Installing gas bottle on cart
1. Tilt the pivoting gas bottle rack down against the floor for easier gas bottle mounting.
2. Move the gas bottle onto the rack.
>> Tilt the gas bottle back and pull the cart towards the gas bottle and push the top of the gas bottle forwards.
The pivot plate assists to lift the bottle into upright position.
3. Secure the gas bottle in place with a strap or a chain. Use the dedicated fixing points in the cart.
© Kemppi
23
1921940 / 2140

Kemppi MasterTig 535ACDC Specifications

General

Brand	Kemppi
Model	MasterTig 535ACDC
Category	Welding System
Language	English
