MasterTig 535ACDC
Operating manual - EN
5.2 Cooling unit MasterTig Cooler MXL
MASTERTIG COOLER MXL
Feature Description Value
Connection voltage U
1
50/60 Hz
220...460 V AC, 1~/3~
Maximum rated supply current I
1max
1.0 A
Rated cooling power at 1 l/min
1.7 kW
Cooling power at 1 l/min
1.7 kW
Recommended coolant
MPG 4456 (Kemppi mixture)
Coolant pressure (max)
0.4 MPa
Tank volume
3.0 l
Operating temperature range *
-20 ... +40 °C
Storage temperature range
-20 ... +60 °C
EMC class
A
Degree of protection **
IP23S
External dimensions L x W x H
825 x 276 x 289 mm
Weight without accessories
25 kg
Standards
IEC 60974-2, -10
* With recommended coolant
** When mounted
© Kemppi
60
1921940 / 2140
