11.2 Interface parameters
1. Press the Menu button to access the menu and
the first menu item “PRoGRM” will be displayed.

2. Use the navigation buttons   to select menu
item „CoM.SET“.
3. Confirm with ENTER key, the currently preset
port will be displayed
oUT.I = RS232
oUT.2 = USB
4. Use the navigation keys to select   „oUT.I“.
5. Press ENTER to save input and the currently
preset baud rate will be displayed.
6. Use the navigation buttons   to select the
desired setting.
7. Press ENTER to save input, the next interface
parameter will be displayed.
Set all interface parameters in turn and then repeat
steps 6 and 7 in each case.
• Baud rate
Selectable settings:
Display B.1200* B.2400 B.4800 B.9600 B.19.2k B.38.4k
Baud rate 1200bps 2400bps 4800bps 9600bps 19.2k bps 38.4k bps
• Parity
Selectable settings:
Display P.NoNE* P.oDD P.EVEN
Parity Small parity, 8 bit Odd parity, 7 bit Straight parity, 7 bit
• Stop bit
Selectable settings:
Display SToP. 1* SToP. 2
Stop bit 1 bit 2 bit
