1 Technical Data
KERN ALS 120-4 ALS 220-4 ALJ 120-4
Readability (d) 0.1 mg 0.1 mg 0.1 mg
Weighing range (Max) 120 g 220 g 120 g
Taring range (subtractive) 120 g 220 g 120 g
Reproducibility 0.2 mg 0.2 mg 0.2 mg
Linearity ± 0.2 mg ± 0.2 mg ± 0.2 mg
Minimal piece weight for
Parts counting
> 0.5 mg > 0.5 mg > 0.5 mg
Recommended adjusting weight,
not included (class)
100 g (E2) 200 g (E2) internal
Warming up time (operating
temperature)
8 h
Verifiable no
Reference piece numbers for
Parts counting
10, 20, 50, freely selectable
Weighing Units mg, g, ct, gn, mom, oz, dwt
Stabilization time (typically) 4 sec.
Permissible ambient temperature + 15° C .... +30° C
Humidity of air max. 80 % (not condensing)
Under floor weighing device Loop for under floor weighing, serial
Housing (W x D x H) mm 206 x 312 x 260
Weighing plate mm 85
Weight kg (net) 6,3
PLS/PLJ/ALS/ALJ-BA-e-0819
37
