Key Automation CT10324 User Manual

2.4 - List of cables required
21
EN
3 - PRELIMINARY CHECKS
The cables required for connection of the various devices in a stan-
dard system are listed in the cables list table.
The cables used must be suitable for the type of installation; for
Before installing the product, perform the following checks and in-
spections:
- check that the gate, the door or the barrier is suitable for automa-
tion;
- the weight and size of the gate or door and the balance of the
barrier boom must be within the operating limits specied for the
automation system in which the product is installed;
- heck that the gate or door has rm, e󰀨ective mechanical safety
stops;
- make sure that the product xing zone is not subject to ooding;
- high acidity or salinity or nearby heat sources might cause the pro-
duct to malfunction;
- in case of extreme weather conditions (e.g. snow, ice, wide tempe-
rature variations or high temperatures), friction may increase, cau-
sing a corresponding rise in the force needed to operate the sy-
stem;
- the starting torque may therefore exceed that required in normal
conditions;
- check that when operated by hand the gate, the door or the barrier
moves smoothly without any areas of greater friction or derail-
ment risk;
- check that the gate, door or the barrier is well balanced and will
therefore remain stationery when released in any position;
- check that the electricity supply line to which the product is to be
connected is suitably earthed and protected by an overload and
di󰀨erential safety breaker device;
- the system power supply line must include a circuit breaker device
with a contact gap allowing complete disconnection in the condi-
tions specied by class III overvoltage;
- ensure that all the material used for installation complies with the
relevant regulatory standards.
example, an H03VV-F type cable is recommended for indoor appli-
cations, while H07RN-F is suitable for outdoor applications.
- Power supply with protection against short-circuits and oveload on
“FLASH”, “LED” and “IND/ELEC” outputs.
- Obstacle detection.
- Automatic learning of stroke.
- Safety device deactivation by means of dip switches: there is no
need to bridge the terminals of safety devices which are not in-
stalled. The function is simply disabled by means of a dip switch.
TECHNICAL SPECIFICATIONS CT10324
Power supply of control board 24 Vac ± 10% - 50/60 Hz
Max motor load 200 W
Max current for “24VAC” output 200 mA (24 Vac)
Max current for “PHPOW” output 200 mA (24 Vdc unregulated)
Max power for “FLASH” output 15 W (24 Vdc)
Max power for “LED” output 15 W (24 Vdc)
Max power for “IND / ELEC” output 5 W (24 Vdc) / 15 VA (12 Vdc)
Fuse of control unit 1.6 AT (time lag)
Max. number of trasmitters storage 150
Operating temperature -20°C +55°C
ELECTRIC CABLE TECHNICAL SPECIFICATIONS
Connection cable maximum allowable limit
Flashing light, courtesy light
Antenna
3 x 0,5 mm
2
1 x cable type RG58
20 m
20 m (advised < 5 m)
Electric lock 1 x cable 2 x 1 mm
2
10 m
Transmitter photocells 1 x cable 2 x 0,5 mm
2
20 m
Receiver photocells 1 x cable 4 x 0,5 mm
2
20 m
Sensitive edge 1 x cable 2 x 0,5 mm
2
20 m
Key-switch 1 x cable 4 x 0,5 mm
2
** 20 m
