- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
3-4 Message Communication
3-34
3
Communicating with the GT2 Series
00H
70H
(112) to
73H
(115)
Reserved for system
74H
(116)
Output1
(HIGH)
Indicates the HIGH output (output 1) status of
each amplifier. When HIGH is output, the bit
corresponding to the ID number of the sensor
amplifier is turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
75H
(117)
Output2
(LOW)
Indicates the LOW output (output 2) status of
each amplifier. When LOW is output, the bit
corresponding to the ID number of the sensor
amplifier is turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
76H
(118)
Output3
(GO)
Indicates the GO output (output 3) status of each
amplifier. When GO is output, the bit
corresponding to the ID number of the sensor
amplifier is turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
77H
(119)
Output4
*1
(HH)
Indicates the status of HH output (output 4) *1 of
each amplifier. When HH is output, the bit
corresponding to the ID number of the sensor
amplifier is turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
78H
(120)
Output5
*1
(LL)
Indicates the status of LL output (output 5) *1 of
each amplifier. When LL is output, the bit
corresponding to the ID number of the sensor
amplifier is turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
79H
(121) to
89H
(137)
Reserved for system
8AH
(138)
Current
Value 0
Invalid
When the current value 0 of each amplifier is
invalid, the bit of corresponding ID number is
turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
8BH
(139)
Current
Value 0
Under Range
When the current value 0 of each amplifier is less
than the lower limit of the detection range,
the bit
of the corresponding ID number is turned ON
.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R WORD
Instance
ID
Attribute
ID
Name Description Attribute
Data
Ty p e
