3-4 Message Communication
3-35
3
Communicating with the GT2 Series
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
00H
8CH
(140)
Current
Value 0
Over Range
When the current value 0 of each amplifier is
higher than the upper limit of the detection range,
the bit of corresponding ID number is turned
ON
.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R
WORD
8DH
(141)
Current
Value 1
Invalid
When the current value 1 of each amplifier is
invalid, the bit of the corresponding ID number is
turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R
WORD
8EH
(142)
Current
Value 1
Under Range
When the current value 1 of each amplifier is less
than the lower limit of the detection range, the bit
of the corresponding ID number is turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R
WORD
8FH
(143)
Current
Value 1 Over
Range
When the current value 1 of each amplifier is
higher than the upper limit of the detection
range, the bit of the corresponding ID number is
turned ON.
Bit 0 to bit 14: ID number 1 to ID number 15
Bit15: Reserved for system
R
WORD
90H
(144)
Current
Value 0 (ID
Number 1)
Indicates the current value 0 of the sensor of ID
number 1.
Parameter range:
-2147483648 to 2147483647 (initial value: 0)
RDINT
91H
(145)
to 9DH
(157)
:
9EH
(158)
Current
Value 0 (ID
Number 15)
Indicates the current value 0 of the sensor ID
number 15.
Parameter range:
-2147483648 to 2147483647 (initial value: 0)
RDINT
9FH
(159)
Reserved for system
A0H
(160)
Current
Value 1 (ID
Number 1)
Indicates the current value 1 of the sensor ID
number 1.
Parameter range:
-2147483648 to 2147483647 (initial value: 0)
RDINT
A1H
(161) to
ADH
(173)
:
AEH
(174)
Current
Value 1 (ID
Number 15)
Indicates the current value 1 of the sensor ID
number 15.
Parameter range:
-2147483648 to 2147483647 (initial value: 0)
RDINT
AFH
(175)
Reserved for system
Instance
ID
Attribute
ID
Name Description
Attribute
Data
Ty p e
To Next Page
