- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
3-4 Message Communication
3-36
3
Communicating with the GT2 Series
*1 If the sensor amplifier is GT2-71MC*, there is no assigned output.
*2 This attribute cannot be used in the GT2-100 Series. The initial value of the
effective ID is read irrespective of the effective ID setting.
For details on current value 0 and current value 1, refer to
"Current
Value 0/Current Value 1" (Page 3-12).
00H
B0H
(176)
Sensor
Status Mask
Setting
Set up the condition to determine if the sensor
error or warning is a recoverable DL-EP1 error
(MS LED blinks in red). If mask is selected, MS
LED does not blink in red when a sensor error or
warning occurs.
Parameter range: 0 to 1 (initial value: 0)
0: Not mask
1: Mask
R/W UINT
B1H
(177)
Sensor
Connected
Number
*2
Indicates the number of connected sensor
amplifiers.
Parameter range: 0 to 15 (initial value: 0)
RUINT
B2H
(178) to
C7H
(199)
Reserved for system
0300H
(768)
Error Code
(ID number
00)
Indicates the error code of ID number 0.
Parameter range: 0 to 65535 (initial value: 0)
RUINT
0301H
(769) to
030EH
(782)
:
030FH
(783)
Error Code
(ID number
15)
Indicates the error code of ID number 15.
Parameter range: 0 to 65535 (initial value: 0)
RUINT
0310H
(784) to
04FFH
(1279)
Reserved for system
Instance
ID
Attribute
ID
Name Description
Attribute
Data
Ty p e
Reference
