Communicating with the GT2 Series
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
● Attributes for GT2 Series (Common to all GT2 Series)
Designate the ID number (01H to 0FH) of a sensor amplifier as the instance ID.
Class
Attribute
ID
Name Description
Attribute
Data
Ty p e
Group1
0320H
(800)
Group1
Entry count
Indicates the number of items (entries) that can
be set in Group 1.
Parameter range: 9
RDINT
0321H
(801)
Sensor
amplifier
error state
Indicates the error status of the sensor amplifier.
bit0: Overcurrent error (ErC)
bit1: Head error (ErH)
bit2: EEPROM error (ErE)
bit3: Jam check error (Er.chK)
bit4: Self-timing delay (Er.dLY)
bit5: Number-of-units error (Er.Unit)
bit6: Calculation error(Er.CAL)
bit7: Calculation-only mode error (Er.noH)
R
DWORD
0322H
(802) to
0323H
(803)
Reserved for system
0324H
(804)
Control
output
Indicates the control output status.
Parameter range: 00H to 1FH (initial value: 00H)
bit0: HIGH output
bit1: LOW output
bit2: GO output
bit3: HH output
*1
bit4: LL output
*1
R
DWORD
0325H
(805)
Comparator
value (P.V.
Value)
*2, *3, *4
Indicates the comparator value (P.V. value).
Parameter range:
-199.9999 to 199.9999 (initial value: 0.0000)
RDINT
0326H
(806)
Raw value
(R.V. Value)
*
2,
*
4,
*
5
Indicates the raw value (R.V. value).
Parameter range:
-199.9999 to 199.9999 (initial value: 0.0000)
RDINT
0327H
(807)
Peak value
during
sampling
*
2
, *
3,
*
4,
*
6
Indicates the peak-hold value in peak-to-peak
mode.
Parameter range:
-199.9999 to 199.9999 (initial value: 0.0000)
RDINT
0328H
(808)
Bottom value
during
sampling
*
2
, *
3
,
*
4,
*
6
Indicates the bottom-hold value in peak-to-peak
mode.
Parameter range:
-199.9999 to 199.9999 (initial value: 0.0000)
RDINT
03
29H
(8
09)
Calculation
display
value
*2, *4, *7
Indicates the calculation display value.
Parameter range:
-199.9999 to 199.9999 (initial value: 0.0000)
RDINT
To Next Page
