Keyence DL-EP1 User Manual

- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (GT2) -
3-4 Message Communication
3-40
3
Communicating with the GT2 Series
Group3
0364H
(868) to
0366H
(870)
Reserved for system
0367H
(871)
Bar display
mode
*11
Indicates bar display mode.
Parameter range: 0 to 1 (initial value: 0)
0: Bar display mode
*11
1: OK/NG display mode
R/W DINT
0368H
(872) to
037FH
(895)
Reserved for system
Group4
0380H
(896)
Group4 Entry
count
Indicates the number of items (entries) that can
be set in Group 4.
Parameter range: 29
RDINT
0381H
(897)
Calculation
mode and
Setting
*12, *18
Indicates calculation mode/calculation setting.
Parameter range: 0 to 27 (initial value: 0)
Tenth place (calculation mode)
0: Does not use the calculation function.
1: Uses the calculation function.
2: Calculation-only mode
Unit digit (calculation setting)
0: Maximum value
1: Minimum value
2: Flatness
3: Average
4: Reference difference
5: Twist
6: Warpage
7: Thickness
(If the calculation function is not used, the
values written into the calculation setting are
invalid.)
R/W DINT
0382H
(898)
Detection
mode
Indicates detection mode.
Parameter range: 0 to 4 (initial value: 0)
0: Standard
1: NG hold
2: Peak hold
3: Bottom hold
4: Peak-to-peak
R/W DINT
0383H
(899)
Hold update
method
Indicates the hold update method.
Parameter range: 0 to 1 (initial value: 0)
0: Timing
1: Regular update
R/W DINT
Class
Attribute
ID
Name Description Attribute
Data
Ty p e
