3 Specifications
36 Keysight 11713D/E Operating and Service Manual
General Specifications
Drive power supply specifications
Specifications below describe warranted performance over the temperature range 0 to +50 °C after
one hour of continuous operation, unless otherwise noted.
Supplemental characteristics
Supplemental characteristics are intended to provide useful information and are typical but
non-warranted performance parameters.
Physical specifications
Table 3-1 11713D/E drive power supply specifications
Current
3.4 A maximum continuous current
Contact pairs 1 through 8, 9, and 0, total maximum current of 3.4 A continuous through all contacts (< 0.7 A per
contact)
Table 3-2 11713D/E supplemental characteristics
Power
100 to 240 Vac, automatic selection, 50/60 Hz
160 VA maximum
Mains supply voltage fluctuations are not to exceed 10% of the nominal supply voltage
Maximum load inductance 500 mH
Model Description Dimension Weight
11713D
With handle and bumper
103.0 mm x 261.3 mm x 378.7 mm (4.06 inches x 10.29 inches x
14.91 inches)
3.5 kg (7.7 lbs)
Without handle and bumper
87.7 mm x 212.7 mm x 364.1 mm (3.45 inches x 8.37 inches x
14.34 inches)
3.1 kg (6.8 lbs)
11713E
With handle and bumper
103.0 mm x 261.3 mm x 378.7 mm (4.06 inches x 10.29 inches x
14.91 inches)
3.6 kg (7.9 lbs)
Without handle and bumper
87.7 mm x 212.7 mm x 364.1 mm (3.45 inches x 8.37 inches x
14.34 inches)
3.2 kg (7.1 lbs)
