7 Remote Interface Configurations
92 Keysight 11713D/E Operating and Service Manual
Connecting the 11713D/E to your Computer
– Keysight IO Libraries Suite for Windows 98/2000/ME/XP. For information and to install, use the
Automation Ready CD with the Keysight IO Libraries Suite, which is shipped with the 11713D/E.
– E2094M Keysight IO Libraries Suite for Windows 98/NT/2000/ME/ XP. You can find information
and install this application via the Web at www.keysight.com/find/iolib.
– You can also access other information about Keysight IO Libraries at www.keysight.com/find/
iolib.
Connecting over GPIB
1 Make sure you have installed the required I/O software on your computer.
2 Follow the instructions included with your GPIB interface card to install the GPIB hardware in
your computer.
3 Connect the GPIB cable (not provided) between the computer and the 11713D/E.
4 Make sure power is applied to your computer and verify that the operating system is fully
booted. Then apply power to 11713D/E.
5 Configure your GPIB hardware as instructed by the documentation provided by the hardware
vendor.
6 Use the Connection Expert utility of the Keysight IO Libraries Suite to add the 11713D/E and
verify a connection.
7 The 11713D/E is shipped from the factory with a default GPIB address of 28. To change the
address, refer to table below:
To easily connect the 11713D/E to your PC, configure and verify your
connection, you can use the Keysight IO Libraries Suite, the E2094M Keysight
IO Libraries for Windows, or and equivalent.
The procedures in this section refer to the Keysight Technologies USB/LAN/
GPIB Interfaces Connectivity Guide. If you have installed the IO Libraries Suite,
you can access the Connectivity Guide via the Keysight IO Libraries Control
icon. Or, you can access the Connectivity Guide via the Web at
www.keysight.com/find/connectivity.
If you have installed any other I/O software, refer to the documentation
included with that software.
