Local Operations 5
Keysight 11713D/E Operating and Service Manual 61
List of default values
Definition
Key operation Factory-shipped setting
Factory
default
key
Preset
(*RST)
Backup
Save/
Recall
Available
means of
defining a
setting
Channel
All Lights ON
[a]
[a] When channel light is ON, it means attenuation is being applied (when attenuator is connected) or switch path is open (when switch is
connected).
<<
[b]
[b] “<<“ symbol shows that the setup is the same as that in the box to the left.
<< * *
K/C
[c]
[c] K = Using front panel. C = Using SCPI command.
Attenuator Type N/A << * * K/C
Supply Voltage +24V << * * K/C
TTL OFF << * * K/C
Beep Volume 8 << * K
GPIB Address 28 << * K
IP Config AUTO << * K
Manual IP Addr “192.168.1.101” << * K
Manual Gateway “0.0.0.0” << * K
Manual Subnet Mask “255.255.255.0” << * K
Factory Default All data that the user can set are cleared. The relay cycle count is not cleared.
Preset
Status when you press Preset key.
*RST
Status when you execute *RST in your program.
Backup
Settings that are backed up (set state not affected by turning power ON/OFF).
In the table, a setting that is automatically backed up is denoted in the following manner:
*: Backup operation performed.
Blank: Backup operation not performed.
Save/Recall
Settings that permit Save/Recall of a setup state.
In the table, states that can be saved/recalled are denoted in the following manner:
*: Save/Recall can be performed.
Blank: Save/Recall cannot be performed.
