Getting Started 3
Series E4360 User’s Guide 45
USB Interface
NOTE
For detailed information about USB interface connections, refer to the
Keysight Technologies USB/LAN/GPIB Interfaces Connectivity Guide,
located on the Automation-Ready CD that is shipped with your product.
The following steps will help you quickly get started connecting your
USB-enabled instrument to the Universal Serial Bus (USB). The following
figure illustrates a typical USB interface system.
1 If you have not already done so, install the Keysight IO Libraries
Suite from the Automation-Ready CD that is shipped with your
product.
2 Connect your instrument to the USB port on your computer.
3 With the Connection Expert utility of the Keysight IO Libraries Suite
running, the computer will automatically recognize the instrument.
This may take several seconds. When the instrument is recognized,
your computer will display the VISA alias, IDN string, and VISA
address. This information is located in the USB folder.
4 Note that you can also view the instrument’s VISA address from the
front panel. Press the Menu key, then use the navigation keys to
select
System\IO\USB\Identification.
5 You can now use Interactive IO within the Connection Expert to
communicate with your instrument, or you can program your
instrument using the various programming environments.
LAN Interface
NOTE
For detailed information about LAN interface connections, refer to the
Keysight Technologies USB/LAN/GPIB Interfaces Connectivity Guide,
located on the Automation-Ready CD that is shipped with your product.
The following steps will help you quickly get started connecting and
configuring your instrument on a local area network. The two types of
local area networks connections that are discussed in this section are
site networks and private networks.
