4 Using the Solar Array Simulator
80 Series E4360 User’s Guide
System-Related Operations
Grouped Channels
Output channels can be configured or “grouped” to create a single
output with higher current and power capability. Refer to Appendix D for
more information.
Instrument State Storage
The SAS has two storage locations in non-volatile memory to store
instrument states. The locations are numbered 0 and 1. Any state
previously stored in the same location will be overwritten.
Select States\SaveRecall.
In the SaveRecall field, enter a
location from 0 to 1, and press
Select. Select Save to save the
state or Recall to recall a state.
To save a state:
*SAV <n>
To recall a state:
*RCL <n>
When shipped from the factory, the SAS is set to automatically recall the
reset (*RST) settings at power-on. However, you can configure the SAS
to use the settings stored in memory location 0 at power-on.
Front Panel:
SCPI Command:
Select States\PowerOn.
Select Recall State 0, then
press Select.
Instrument Identification
For Keysight E4360 mainframes, you can return the model number,
serial number, firmware revision, backup and active firmware. For output
modules, you can return the
model number, serial number, installed
options, voltage, current and power rating.
Select System\About\Frame.
or
Select System\About\Module.
SYST:CHAN:MOD? (@1)
SYST:CHAN:OPT? (@1)
